Abstract
In this paper, the behavior of a plasmonic filter structured around a metal-air-metal waveguide incorporating a washer-like resonator was investigated. The transmittance spectrum and magnetic field (Hz) distributions were analyzed using the finite element method (FEM) within the COMSOL Multiphysics software (version 6.0). The impact of various geometrical parameters-such as width of the washer (????), gap width (????), external radius of the washer, and material configuration on the optical characteristics of the filter including transmission, reflection, and absorption were thoroughly examined. Our results showed that enlarging the value of ???? led to a redshift in the transmission spectrum and strengthened the resonant interaction, whereas narrowing ???? weakened the optical coupling and shifted the spectrum toward the blue region. Hence, the observed spectral shifts and tunable features emphasized the filter’s adaptability, which can be leveraged in various photonic and nano-optical platforms with minimal structural changes. We observed that the full width at half maximum (FWHM) and quality factor were significantly affected by the washer radius and structure length, highlighting the resonance resolution and transmittance efficiency. The proposed filter achieved transmission exceeding 70%, a quality factor of up to 70, and a bandwidth of 10 nm. These values were obtained at the resonance wavelength of 800 nm. Furthermore, comparing the results between silver and gold using the Drude model revealed that gold offered a lower transmission efficiency and quality factor comparing to silver. We did not focus on gold, as it has low absorbency, making it an ideal choice for high-performance optical filtering applications. These insights contributed to the advancement of tunable plasmonic systems used in fields like optical sensing and spectral filtering.
Keywords
FWHM
plasmonic filter
quality factor.
Surface Plasmon Resonance
